Specification:
Physical Parameters
Material
ABS+PVC+PC
Size
L*W*H: 162mm * 68mm * 93mm
Weight
169g±5g(without cord)
Power Supply
5V ±5% ,Built-in 3.7v 1500mAh lithium-ion battery
Operating current
50MA(operating mode); 30MA(standby mode)100MA(maximum peak)
Color
white,black
Button Lifespan
>100000
Performance Parameters
Interface
USB cable;Wireless 2.4G transmission
System Supported
Linux,Android,Windows XP,7,8,10,MAC
Language Supported
English(Customizable language)
Light source
Visible laser diode, wavelength 650nm
Processor
32-bit MCU
Memory
64K(About 3500 14bit 1D barcodes)(the memory capacity can be customized)
Scanning speed
200 scans/sec
Resolution
4mil
Transmission Distance
70m
Bit Error Rate
1/5000000
Reading Mode
laser
Trigger Mode
Manual ;Continuous scanning
Prompt Mode
Buzzer, Indicator Light(LED)
Print Contrast
35%
Charging time
6-7 hours
Working time
about 24 hours
Decoding
Capability
Code25-Interleaved    Code25-Standard        Code25-Matri
Code39-Regular        Code39-FullASCII       Code32
Code93-Regular        Code93-FullASCII       Code128
Scanning Distance
10mm-600mm
Scanning Angel
Roll35°;Pitch65°;Yew65°
Scanning Depth
Code39  5mil:3cm - 8cm
 Code39 10mil:4cm - 45cm
Environment Parameters
IP Grade
IP52
Operating Temp.
0 to 50ºC / 32 to 122ºF
Storage Temp.
0 to 50ºC / 32 to 122ºF
Operating Humidity
20% to 85%(No Condensation)
Storage Humidity
20% to 85%(No Condensation)
ESD Protection
15KV air discharge
Shock Resistance
1.5m free fall on concrete surface
